Multimode RF transceiver advances WEDGE radio system

Wireless communications are evolving at an ever-increasing rate. Systems suchas GSM, EDGE and CDMA are being augmented with 3G and Wi-Fi capabilities,making an efficient and cost-effective multimode solution essential. The RF transceiver is a key ingredient of any multimode solution. Its design presents several challenges that are magnified when distinctly different modes such as GSM and WCDMA must both be hosted. This article examines some of the challenges related to multimode transceiver design, and presents a highly integrated, multimode RF transceiver solution that addresses the needs of GSM, EDGE and WCDMA.



Wireless standards necessarily pursue a dual path of consolidation
and expansion, as if this were a law of nature. Market
forces demand this. Wi-Fi solution providers were quick to integrate
802.11a/g with their 802.11b solutions. GSM solutions necessarily
integrated EDGE. In the same manner, combined GSM-EDGEWCDMA
solutions are also unavoidable.
These same market forces drive the multimode aspect of transceiver
design as well as the multiband perspective. Solutions that were
acceptable for single- or dual-band applications may not be acceptable
for triple- and quad-band service where external component cost and
size become unacceptable. Transceiver designers must be increasingly
forward-looking in anticipation of these factors, while at the same time
employ measured restraint so that present customer demands are well
served in the near-term. The discussion that follows focuses on attaining
some of the more demanding requirements that are commensurate with
a highly integrated GSM-EDGE-WCDMA transceiver solution, and the
role these requirements play in transceiver architecture selection.



Receiver considerations
Industry-favored solutions for GSM-EDGE have converged to
primarily one of two choices for the receive architecture: a) directconversion
or b) low-IF. Aside from complexity and low-cost features
that these architectures provide, several technical issues have warranted
these choices.
GSM-EDGE requires IP2 performance on the order of 50 dBm or
more when referred to the antenna input. This requirement amplifies
the already challenging issues pertaining to dc offsets in the receiver.
Direct-conversion receivers struggle with this problem more than
low-IF receivers since the dc component falls directly within the
receive bandwidth. The dc offset is also time varying because it is
driven by dynamic adjacent-channel interferers. It also is affected
by local oscillator (LO) leakage, low-noise amplifier (LNA) gain, and
temperature.
CMOS designs must also contend with fairly severe 1/f noise in
the sensitive IQ gain stages that immediately follow the downconversion
mixer. Detailed 1/f noise parameters depend significantly
on oxide thickness and channel length. RF CMOS technologies
in the 130 nm to 180 nm realm generally exhibit 1/f corner
frequencies on the order of several hundred kHz, thereby making the
low-IF architecture attractive for this reason. Issues of dc offset
are not eliminated entirely with the low-IF architecture, but the
severity is reduced.






Most WCDMA receivers have adopted
the zero-IF architecture.Owing to WCDMA’s
much wider modulationbandwidth, dc
offset issues are moreeasily addressed than
for GSM-EDGE. The bandwidth argument
also reduces the 1/fnoise issue because
(i) its impact on the overall receive signalto-
noise ratio (SNR) is considerably less,
and (ii) this noise is spread across multiple chips of the WCDMA waveform where it can be
effectively tracked out by the baseband signal processing if desired.
One of the major problems facing WCDMA receiver design pertains
to transmitter leakage that falls through the duplexer filtering into the LNA input.
This leakage adversely impacts attaining receiver
IP2 and IP3 requirements, and normally requires band-specific SAW
filters to be used between the LNA outputs and the mixer input.
In WCDMA low-band, the transmit signal is offset from the receive
signal by a scant 45 MHz whereas the offset is increased to 190
MHz for the IMT band near 2 GHz. These offsets combined with the
required filter attenuation that is needed make the on-chip filtering
option quite challenging. Since the filter follows immediately after
the LNA, its insertion loss must be reasonable or else additional
constraints are imposed on the LNA gain. As shown in Figure 1, the ratio
of inductor-Q to filter-Q must be at least a factor of four in order to
have a reasonably small insertion loss.













To View the complete Article from Jim Crawford, Please Visit his Website HERE

Radio Architectures, Pt 3: Intermodulation and Intercept Points

Intermodulation and Intercept Points
The mixer generates intermediate freqeuency (IF) signals that result from the sum and difference of the LO and RF signals combined in the mixer:

These sum and difference signals at the IF port are of equal amplitude, but generally only the difference signal is desired for processing and demodulation so the sum frequency (also known as the image signal: see Fig. 8-11) must be removed, typically by means of IF bandpass or lowpass filtering.

A secondary IF signal, which can be called f*IF, is also produced at the IF port as a result of the sum frequency reflecting back into the mixer and combining with the second harmonic of the LO signal.

Mathematically, this secondary signal appears as:

This secondary IF signal is at the same frequency as the primary IF signal. Unfortunately, differences in phase between the two signals typically result in uneven mixer conversion-loss response. But flat IF response can be achieved by maintaining constant impedance between the IF port and following component load (IF filter and amplifier) so that the sum frequency signals are prevented from re-entering the mixer. In terms of discrete components, some manufacturers offer constant-impedance IF bandpass filters that serve to minimize the disruptive reflection of these secondary IF signals. Such filters attenuate the unwanted sum frequency signals by absorption. Essentially, the return loss of the filter determines the level of the sum frequency signal that is reflected back into the mixer.

If a mixer’s IF port is terminated with a conventional IF filter, such as a bandpass or lowpass type, the sum frequency signal will re-enter the mixer and generate intermodulation distortion. One of the main intermodulation products of concern is the two-tone, third-order product, which is separated from the IF by the same frequency spacing as the RF signal. These intermodulation frequencies are a result of the mixing of spurious and harmonic responses from the LO and the input RF signals:

But by careful impedance matching of the IF filter to the mixer’s IF port, the effects of the sum frequency products and their intermodulation distortion can be minimized.

EXAMPLE: Intermodulation and Intercept Points
To get a better understanding of intermodulation products, let’s consider the simple case of two frequencies, say f1 and f2. To define the products, we add the harmonic multiplying constants of the two frequencies. For example, the second order intermodulation products are (f1 +f2); the third order are (2f1 ‘f2); the fourth order are (2f1 +f2); the fifth order are (3f1 ‘f2); etc. If f1 and f2 are two frequencies of 100 kHz and 101 kHz (that is, 1 kHz apart) then we get the intermodulation products as shown in Table 8-1.

From the table it becomes apparent that only the odd order intermodulation products are close to the two fundamental frequencies of f1 and f2. Note that one third order product (2f1‘f2) is only 1 kHz lower in frequency than f1 and another (2f2 ‘f1) is only 1 kHz above f2. The fifth order product is also closer to the fundamentals than corresponding even order products.

These odd order intermodulation products are of interest in the first mixer state of a superheterodyne receiver. As we have seen earlier, the very function of a mixer stage—namely, forming an intermediate lower frequency from the sum/difference of the input signal and a local oscillatory—results in the production of nonlinearity. Not surprisingly, the mixer stage is a primary source of unwanted intermodulation products. Consider this example: A receiver is tuned to a signal on 1000 kHz but there are also two strong signals, f1on 1020 kHz and f2 on 1040 kHz. The closest signal is only 20 kHz away.

Our IF stage filter is sharp with a 2.5-kHz bandwidth, which is quite capable of rejecting the unwanted 1020-kHz signal. However, the RF stages before the mixer are not so selective and the two signals f1 and f2 are seen at the mixer input. As such, intermodulation components are readily produced, including a third order intermodulation component (2f1 ‘f2) at (2-1020’1040)=1000 kHz. This intermodulation product lies right on our input signal frequency! Such intermodulation components or out-of-band signals can easily cause interference within the working band of the receiver.

In terms of physical measurements, the two-tone, third-order intermodulation is the easiest to measure of the intermodulation interferences in an RF system. All that is needed is to have two carriers of equal power levels that are near the same frequency. The result of this measurement is used to determine the third-order intermodulation intercept point (IIP3), a theoretical level used to calculate third-order intermodulation levels at any total power level significantly lower than the intercept point.
